Crommelins Standby Generator Three Phase 14.0kVA

00364
AU$0.00
In stock
1
Product Details

Standby Generator with Kubota diesel engine, Deep Sea controller.

This Crommelins generator standby outputs 11.2 Kw (14.0kVA max.) is for powering worksites, homes and for solar power backup needs.

The three-phase generator features a Japanese water-cooled Kubota diesel engine, Stamford alternator, and a Deep Sea Controller all coming in a heavy-duty compact silenced canopy with central lifting hook and also forklift pockets.

This generator has switched single and three-phase outlets for instant use, as well as a pre-wired socket outlet for ATS (Auto transfer switch). There is also a two-wire remote start plug and hardwire facility making for simple use and installation. A generous 55L fuel tank assures 28hr running time at 75% load.

Backed by Crommelins Machinery Australia wide support and service network. Please note lead times may apply.

SPECIFICATIONS

Model Number CHK13S3
Prime 13kVA / 10.8kw
Standby 14kVA / 11.2kw
Starting System Electric Start
Phase Three
Fuel Type Diesel
15amp outlet s/phase 1x 15Amp
32amp outlet 3/phase 1x 32Amp
Alternator Stamford PI044G
Output Amps 18.1 / 19.5A
Voltage (V) 415v – 50hz
Engine Power/Model D1703-BG
Engine Brand Kubota
Fuel Tank (L) 55L
Running Time (Rated Output) 28hr
Noise Level (dB @ 7m) 63db
Weight (kg) 601kg
Dimensions (LxWxH) 1782 x 868 x 1115mm
Package (LxWxH) 1782 x 868 x 1115mm
Manufacturers Warranty 1 Year
