Crommelins Standby Generator Three Phase 33.0kVA

Standby Generator with Kubota diesel engine, Deep Sea controller.

This Crommelins generator standby outputs 26.4 Kw (33.0kVA max.) is for powering worksites, homes and for solar power backup needs.

The three-phase generator features a Japanese water-cooled Kubota diesel engine, Stamford alternator, and a Deep Sea Controller all coming in a heavy-duty compact silenced canopy with central lifting hook and also forklift pockets.

This generator has switched single and three-phase outlets for instant use, as well as a pre-wired socket outlet for ATS (Auto transfer switch). There is also a two-wire remote start plug and hardwire facility making for simple use and installation. A generous 127L fuel tank assures 34hr running time at 75% load. Watch it in aciton here.

Backed by Crommelins Machinery Australia wide support and service network. Please note lead times may apply.

SPECIFICATIONS

Model Number	CHK30S3
Prime	30kVA / 24kw
Standby	33kVA / 26.4kw
Starting System	Electric Start
Phase	Three
Fuel Type	Diesel
15amp outlet s/phase	2x 15Amp
20amp outlet s/phase	1x 20Amp
32amp outlet 3/phase	1x 32Amp
Alternator	Stamford PI144G
Output Amps	41.7 / 45.9A
Voltage (V)	415v – 50hz
Engine Power/Model	V3300-BG
Engine Brand	Kubota
Fuel Tank (L)	127L
Running Time (Rated Output)	34hr
Noise Level (dB @ 7m)	65db
Weight (kg)	930kg
Dimensions (LxWxH)	2000 x 925 x 1300mm
Package (LxWxH)	2000 x 925 x 1300mm
Manufacturers Warranty	1 Year
